Intelligent media motherboard robot motherboard subway screen main control board display motherboard

Short Description:

Multi -functional intelligent media motherboard MC1001V1 is based on the T3 platform of the full -minded car regulatory chip T3 platform. It is mainly used for the content display and intelligent control of the vehicle LCD display product. It can also be used for smart display terminal products, video terminal products, industrial automation terminal products, etc. Support H.264 hard decoding, Ethernet flow media coding, network linkage control, etc. Data synchronization control adopts the mode of RS485 and Ethernet.


Product Detail

Product Tags

Overview

Industrial automation control system
  • Support remote OTA, which can achieve UI, applications, and remote upgrades at the bottom;
  • Support infrared remote control, automatic backlight brightness adjustment, U disk and SD card storage expansion function;
  • Support energy -saving mode, and ultra -low power standby;
  • Support the system's self -recovery function. After the system is abnormal or the main chip is abnormal, the system detects the MCU to restart the motherboard;
  • Using our display UI visual editing software can achieve display new UI design, UI modification, UI upgrade, etc.;
  • Reading, parameter modification, remote upgrade, log query and analysis can be read through the upper machine or management platform;
  • Support the intelligent detection function of the device. The system can detect the built -in module and network status of the device. You can actively report the device failure, the intelligent Bypass network active switching, the display of the screenshot of the display content;
  • Car-level design, which meets the ultra-width temperature -40 ℃ ～+85 ℃. The surface of the motherboard has three anti-coating protection, which can prevent moisture, salt fog, and mold.
  • The motherboard meets 100,000 hours of super long service life;
  • In line with the relevant standards of EN50155, EN50121, EN50126, IEC61373 in the rail industry, effectively prevent vibration, high temperature, low temperature and electromagnetic interference;
  • PCB board reaches UL94LV-0 fire prevention level requirements;
  • Consistent with the relevant standards of automotive electronic GB/T_28046
  • Uses/application field

Detailed Information

Multi -functional intelligent media motherboard MC1001V1 is based on the T3 platform of the full -minded car regulatory chip T3 platform. It is mainly used for the content display and intelligent control of the vehicle LCD display product. It can also be used for smart display terminal products, video terminal products, industrial automation terminal products, etc. Support H.264 hard decoding, Ethernet flow media coding, network linkage control, etc. Data synchronization control adopts the mode of RS485 and Ethernet. The two network communication methods can be actively switched to each other, and mutual redundant backup. The motherboard via the LVDS interface 1 and LVDS interface 2, two dual -channel LVDS interfaces, which can realize the two -screen different display dual -screen and display function. Each interface supports the maximum resolution 1920*1080 60Hz, and the video output format VESA and Jeida. Support dual -screen with different display and dual -screen different display; support the flexible design of different voltage LCD modules. Feature description

Apply to

  • Rail Transit Train Auto Electronic Dynamic Map LCD screen
  • Rail Transit train car media LCD screen (IPTV)
  • Smart buses carrying electronic dynamic map LCD screen
  • Bus car advertising machine
  • Smart LCD boot screen
  • Advertising machine
  • Digital signs
  • Work control host
  • Smart retail terminal robot equipment

FAQs

Q1. What is needed for quotation?

A: PCB : Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...).
PCBA: PCB information, BOM, (Testing documents...).

Q2. What file formats do you accept for production?

A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF, word, txt).

Q3. Are my files safe?

A: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.

Q4. MOQ?

A: There is no MOQ. We are able to handle Small as well as large volume production with flexibility.

Q5. Shipping cost?

A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.

Q6. Do you accept process materials supplied by clients?

A: Yes, we can provide component source, and we also accept component from client.
