Double-sided PCB IMS Matt black solder mask HASL LF for Automotive lamp

Short Description:

Key Specifications/ Special Features:

We are PCB mass production manufacturer in Shenzhen province China, with UL and TS 16949 approved, our location is close to Shanghai with convenient transportation.

Our products which is widely used in LED indoor and outdoor lighting, car lighting and back lighting fields and more,

All MC PCBs are custom-made, please send Gerber file and requirements for a quote.

Model Number: XinDaChangPCB-9-IMS#12524-#18639-#4588

Brand Name: XinDaChang

Origin: China

Small Orders: Accepted

Send email to us

Product Detail

Product Tags

Product Specification:

Layers	1-2 Layers
Finished Thickness	16-134mil (0.4mm-3.4mm )
Max. Dimension	500mm *1200mm
Copper Thickness	35um, 70um,1 to 10oZ
Min Line Width/Space	4mil (0.1mm )
Min Finished Hole Size	0.95mm
Min. Drill Size	1.00mm
Max. Drill Size	6.5mm
Finished Hole Size Tolerance	±0.050mm
Aperture Position Precision	±0.076mm
Min SMT PAD Size	0.4mm±0.1mm
Min.Solder Mask PAD	0.05mm(2mil)
Min.Solder Mask Cover	0.05mm(2mil)
Solder mask Thickness	>12um
Surface Finishing	HAL, HAL Lead free,OSP, Immersion Gold, etc
HAL Thickness	5-12um
Immersion Gold Thickness	1-3mil
OSP Film Thickness	ENTEK PLUS HT:0.3-0.5um; F2:0.15-0.3um
Outline Finishing	Routing & Punching; Precision Deviation ±0.10mm
Thermal Conductivity	1.0 to 12w/m.k

Advantage

10 years' experience in MC PCB Manufacturing.
Certified by ISO/TS 16949, ISO 14001 and UL, completely follows ISO 9001:2008 quality control
100% E-test before shipping.
24hours for running to ensure stable delivery time.

Shipping Information

FOB Port	Shenzhen
Export Carton Dimensions L/W/H	36 x 26 x 25 Centimeters
Lead Time	3–7 days
Units per Export Carton	5.0
Export Carton Weight	18 Kilograms
